Articulated Arm PV Cleaning Robot
Jupiter

Articulated Arm PV Cleaning Robot
Jupiter

Product Highlights

  • All-terrain capability, multi-scenario coverage
  • Autonomous operation, intelligent decision-making
  • Rapid response
  • High-efficiency，safe and reliable
· ≥8h operation with wireless fast charging, 7-14MW per day coverage
· Unique flexible robotic arm; 24/7 autonomous operation; suits all-day, all-weather and all-terrain scenarios
· Global navigation positioning and intelligent path planning support automatic docking charging and breakpoint resumption
· SmartPure enables data analysis, intelligent decision-making, and visualized management
· No engineering modifications required; multi-docks charging; all layout adaptable; deployment cycle reduced by 90%
· 360° stereoscopic sensing, high-precision positioning
· High-efficiency cleaning brush, 100% full coverage, cleaning efficiency reach to 99.5%
· 100% brush-to-module contact with precise distance control and flexible anti-collision

Technical Specifications

General and mechanical

  • Weight

    2.5 T

  • Max cleaning speed

    2.5 km/h

  • Optimal cleaning speed

    1.5 km/h

  • Travel speed

    3 km/h

  • Chassis type

    Crawler

  • Cleaning type

    Dry cleaning

  • Operating temperature

    -20°C-60°C

  • Storage temperature

    -40°C-60°C

  • IP rating

    IP65

  • Brush length

    3 m-6 m

  • Brush rotation speed

    200 rpm

  • Brush head swivel angle

    360°

  • Cleaning efficiency

    99.5% (Daily cleaning)

  • Corrosion resistance level

    C4

  • Module coverage ratio

    100%

  • Charge time

    5 h

  • Operating range

    12.5 km

  • Operating time

    ≥ 8h

  • Battery cycle life

    2000 cycles

Adaptive capability

  • Obstacle clearance height

    200 mm

  • Trench crossing capacity

    400 mm

  • Max gradeability

    25°

  • Min row spacing clearance

    2 m

  • Turning radius

    2.5 m

  • Module tilt angle

    0-60° (1P、2P)

Communication and management

  • Control mode

    Full autonomy

  • Brush adjustment

    Adaptive

  • Path planning

    Autonomous navigation

  • Safety mechanism

    Hardware-software integrated safeguards
